The Head 2 59gr.(HyperCap & bolt included)

The weightweenie chioice.

Improvements are on every single part of the original The Head.

Slimmer, lighter and trickier: a real concentrate
of our Extralite high-quality engineering.



Sealing: 4 RS + 2 O-Rings.

Stack Height: 10.5 + 10mm.

Weight: 59gr.(HyperCap & bolt included).

Upper Bearing: Radial micro cartridge.

Lower Bearing: Stainless bidirectional cartridge.

Standard: 34mm frame head tube*.

Finish: black/bronze anodized.

Graphics: laser etched.

(*) Frame standard 34mm (tolerance 33.95 to 34.00mm); measure refers to frame steer tube internal diameter measured at headset fitting level.

Reduced vertical dimensions allow efficient bike layouts, as example you can use a longer
travel fork while keeping your actual bar level.

Japanese M-X technology shows how to divide upper bearing (micro-radial)
and lower bearing (stainless, bidirectional) steering functions; an ultra tricky layout
that shrinks headset upper section, reducing weight and improving your x-c raceing trim.

Warning: UPPER RADIAL MICRO BEARING CANNOT HANDLE UPSIDE-DOWN LOADS/SHOCKS.

Suitable for x-c single crown or road forks only.

Available in 1 1/8' standard size only.



100% made in Italy
